Super Octode 521AR

Super Octode 521AR; Philips Ibérica, (ID = 2001391) Radio Super Octode 521AR; Philips Ibérica, (ID = 2001395) Radio
Super Octode 521AR; Philips Ibérica, (ID = 2001399) Radio Super Octode 521AR; Philips Ibérica, (ID = 2001401) Radio
Super Octode 521AR; Philips Ibérica, (ID = 2001402) Radio Super Octode 521AR; Philips Ibérica, (ID = 2001404) Radio
Super Octode 521AR; Philips Ibérica, (ID = 2001405) Radio Super Octode 521AR; Philips Ibérica, (ID = 2001406) Radio
Super Octode 521AR; Philips Ibérica, (ID = 2001407) Radio Super Octode 521AR; Philips Ibérica, (ID = 2001408) Radio
Use red slider bar for more.
Super Octode 521AR; Philips Ibérica, (ID = 2001391) Radio
Philips Ibérica,: Super Octode 521AR [Radio] ID = 2001391 1008x756
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super Octode 521AR, Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes, SELEZ; Madrid, Barcelona

Country:  Spain
Manufacturer / Brand:  Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes, SELEZ; Madrid, Barcelona
Year: 1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: AK1 AF2 E446 AB1 E443H 506
Main principle Superheterodyne (common)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 103; 111; 118; 127; 135; 143; 155; 196; 210; 225; 240; 253 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Super Octode 521AR - Philips Ibérica, COPRESA,
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 360 x 280 x 200 mm / 14.2 x 11 x 7.9 inch
Notes

Philips Ibérica 521 AR

El anuncio indica mal las bandas de los dos aparatos siendo las correctas OM-OL para el 521A y OM-OC para el 521AR

Net weight (2.2 lb = 1 kg) 7.9 kg / 17 lb 6.4 oz (17.401 lb)
Price in first year of sale 495.00 ESP
Mentioned in Anuncio revista Radio-Técnica Septiembre 1935

Model page created by Miguel Bravo-Cos. See "Data change" for further contributors.
