HiQ-Sound 22CS5440/16R (GTV-0002)
Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes, SELEZ; Madrid, Barcelona
- Country
- Spain
- Manufacturer / Brand
- Philips Ibérica, COPRESA, Compañía de Productos Electrónicos, Miniwatt tubes, SELEZ; Madrid, Barcelona
- Year
- 1986
- Category
- Television Receiver (TV) or Monitor
- Radiomuseum.org ID
- 217666
- Number of Tubes
- 1
- Valves / Tubes
- A56-540X
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superhet with RF-stage
- Wave bands
- VHF incl. FM and/or UHF (see notes for details)
- Details
- Radio Control (+Remote Wire etc)
- Power type and voltage
- Alternating Current supply (AC) / 220 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical / Ø 15 cm = 5.9 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: HiQ-Sound 22CS5440/16R - Philips Ibérica, COPRESA,
- Shape
- Tablemodel, low profile (big size).
- Dimensions (WHD)
- 650 x 400 x 460 mm / 25.6 x 15.7 x 18.1 inch
- Notes
-
Philips Ibérica, S.A.E. (Copresa), 22CS5440 /16R
TV Color 22" PAL, CCIR B/G. 5300 Remote Control. Scart terminal. 78 W power consumption.
Altavoz elíptico 15" x ?"
Véanse modelos similares con la misma contraseña de homologación GTV-0002
- Philips Ibérica 22CS-5048 /16Z (No)
- Philips Ibérica 22CS-5140 /16Z (No)
- Philips Ibérica 22CS-5540 /16R (No)
- Radiola (Philips Ibérica) 56KS-5080 /16Z (No)
- Radiola (Philips Ibérica) 56KS-5402 /16Z (Si)
Mando a distancia (Si) / (No)
- Price in first year of sale
- 87,500.00 PTE
- Mentioned in
- B.O.E. 191 del 11 de agosto de 1986 página 28334
- Author
- Model page created by Gil Silva. See "Data change" for further contributors.
