Radioplayer 666A
Philips Electrical Industries of New Zealand Ltd.; Wellington
- Country
- New Zealand-Aotearoa
- Manufacturer / Brand
- Philips Electrical Industries of New Zealand Ltd.; Wellington
- Year
- 1934
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 338169
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 6
- Main principle
- Superhet with RF-stage; 2 AF stage(s)
- Tuned circuits
- 7 AM circuit(s)
- Wave bands
- Broadcast and Short Wave (SW).
- Power type and voltage
- Alternating Current supply (AC) / 230 Volt
- Loudspeaker
- Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
- Power out
- 2 W (undistorted)
- Material
- Wooden case
- from Radiomuseum.org
- Model: Radioplayer 666A - Philips Electrical Industries
- Shape
- Tablemodel, Tombstone = decorative upright, not cathedral but can have rounded edges.
- Notes
-
6-valve superhet with RF stage dual wave receiver.
IF 256 kc/s but it was necessary to alter this to 285 kc/s in Wellington and Dunedin due to the effect of two powerful stations producing a beat equal to the 256 IF causing an apparent lack of sensitivity.
Appeared in 2 table cabinet styles and also available as a console model.
Manufactured by Radio Corporation Of New Zealand Ltd using Philips valves.
- Mentioned in
- -- Original prospect or advert (Manawatu Times 19 March 1935 Page 3)
- Literature/Schematics (1)
- More Golden Age of Radio (Page 115)
- Author
- Model page created by Brian Stevens. See "Data change" for further contributors.
