Concert 2000

Concert 2000; Phonotechnik Pirna/ (ID = 135981) R-Player Concert 2000; Phonotechnik Pirna/ (ID = 135982) R-Player
Concert 2000; Phonotechnik Pirna/ (ID = 135983) R-Player Concert 2000; Phonotechnik Pirna/ (ID = 135984) R-Player
Concert 2000; Phonotechnik Pirna/ (ID = 575566) R-Player Concert 2000; Phonotechnik Pirna/ (ID = 575567) R-Player
Concert 2000; Phonotechnik Pirna/ (ID = 575568) R-Player Concert 2000; Phonotechnik Pirna/ (ID = 575569) R-Player
Use red slider bar for more.
Concert 2000; Phonotechnik Pirna/ (ID = 135981) R-Player
Phonotechnik Pirna/: Concert 2000 [R-Player] ID = 135981 932x699
Select picture or schematic to display from thumbnails on the right and click for download.
For model Concert 2000, Phonotechnik Pirna/Zittau; VEB; (Ostd.); Marke: Ziphona

Country:  Germany
Manufacturer / Brand:  Phonotechnik Pirna/Zittau; VEB; (Ostd.); Marke: Ziphona
Year: 1981/1982 Category: Sound/Video Recorder and/or Player
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details Rec.Player+Audio.Amp+LS
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Concert 2000 - Phonotechnik Pirna/Zittau; VEB
Material Various materials
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 450 x 170 x 400 mm / 17.7 x 6.7 x 15.7 inch
Notes Antrieb mit geschliffenem Flachriemen. 4 Transistoren, Schaltkreise A 273 D und A 274 D ,MDA 2020 2 x , Ausgangsleistung sinus : 2x13 Watt, Übertragungsbereich System CS 24 SD 31,5...14 Khz. Automatisches und manuelles abspielen möglioch. Preis incl. 2 Boxen B9131 (15W, 4 Ohm).
Net weight (2.2 lb = 1 kg) 10 kg / 22 lb 0.4 oz (22.026 lb)
Price in first year of sale 1'180.00 DM
Collectors' prices
Source of data Radiokatalog Band 2, Ernst Erb
Mentioned in -- Original prospect or advert (Der Fachberater Technik 1/81)
