• Country
• Germany

• Manufacturer / Brand
• Phonotechnik Pirna/Zittau; VEB; (Ostd.); Marke: Ziphona

• Year
• 1982 ?

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 127792

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 16

• Semiconductors

• Main principle
• Audio-Amplification; 2 AF stage(s); none

• Wave bands
• - without

• Details
• Record Player (not changer)

• Power type and voltage
• Alternating Current supply (AC) / 220 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Power out
• 20 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Rubin 2020 Stereo - Phonotechnik Pirna/Zittau; VEB

• Shape
• Book-shelf unit.

• Dimensions (WHD)
• 476 x 163 x 346 mm / 18.7 x 6.4 x 13.6 inch

• Notes
• Ausgangsleistung: 2x10 W Sinus.

• Net weight (2.2 lb = 1 kg)
• 9 kg / 19 lb 13.2 oz (19.824 lb)

• External source of data
• Serviceanleitung

• Literature/Schematics (1)
• -- Original prospect or advert

• Author
• Model page created by Egon Strampe. See "Data change" for further contributors.
