599

599; Phonola SA, FIMI; (ID = 258388) Radio

599; Phonola SA, FIMI; (ID = 258389) Radio
599; Phonola SA, FIMI; (ID = 275356) Radio 599; Phonola SA, FIMI; (ID = 275357) Radio
599; Phonola SA, FIMI; (ID = 2253547) Radio
Use red slider bar for more.
599; Phonola SA, FIMI; (ID = 275356) Radio
Phonola SA, FIMI;: 599 [Radio] ID = 275356 640x480
Select picture or schematic to display from thumbnails on the right and click for download.
For model 599, Phonola SA, FIMI; Saronno (VA)

Country:  Italy
Manufacturer / Brand:  Phonola SA, FIMI; Saronno (VA)
Year: 1950/1951 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 12BE6 12BA6 12AT6 50B5 35W4
Main principle Super-Heterodyne (Super in general); ZF/IF 470 kHz
Wave bands Wave Bands given in the notes.
Details
Power type and voltage AC/DC-set / 115; 125; 140; 160 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 10 cm = 3.9 inch
Power out 1.2 W (unknown quality)
from Radiomuseum.org Model: 599 - Phonola SA, FIMI; Saronno VA
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 210 x 139 x 110 mm / 8.3 x 5.5 x 4.3 inch
Notes

Diverse varianti di colore.

Gamme d'onda: 2× OM, 2× OC (OM1 520-720 Kc,OM2 680-1650 Kc, OC1 6-8,1 Mc, OC2 7,8-18,1 Mc).
Wave bands: 2× BC, 2× SW.

Price in first year of sale 27'000.00 ITL
Source of data Guida Pratica Antique Radio IV (2001)
Mentioned in -- Original prospect or advert
Literature/Schematics (1) Schemi di apparecchi radio ( Ravalico 1953 ) (pag. 247-248)

Model page created by Alessandro De Poi. See "Data change" for further contributors.
