740-1

740-1; Phonola SA, FIMI; (ID = 1330899) Radio

740-1; Phonola SA, FIMI; (ID = 1612586) Radio

740-1; Phonola SA, FIMI; (ID = 1612587) Radio
740-1; Phonola SA, FIMI; (ID = 1612608) Radio 740-1; Phonola SA, FIMI; (ID = 1612588) Radio
740-1; Phonola SA, FIMI; (ID = 1612593) Radio 740-1; Phonola SA, FIMI; (ID = 1612597) Radio
740-1; Phonola SA, FIMI; (ID = 1612601) Radio 740-1; Phonola SA, FIMI; (ID = 1612603) Radio
740-1; Phonola SA, FIMI; (ID = 1612605) Radio 740-1; Phonola SA, FIMI; (ID = 1612606) Radio
740-1; Phonola SA, FIMI; (ID = 1612609) Radio 740-1; Phonola SA, FIMI; (ID = 1612612) Radio
Use red slider bar for more.
740-1; Phonola SA, FIMI; (ID = 1612608) Radio
Phonola SA, FIMI;: 740-1 [Radio] ID = 1612608 933x592
Select picture or schematic to display from thumbnails on the right and click for download.
For model 740-1, Phonola SA, FIMI; Saronno (VA)

Country:  Italy
Manufacturer / Brand:  Phonola SA, FIMI; Saronno (VA)
Year: 1935/1936 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 7: AK1 AF2 AB1 E446 E443H E443H 1561
Main principle Superhet, IF regeneration; ZF/IF 470 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 26 cm = 10.2 inch
Power out
from Radiomuseum.org Model: 740-1 - Phonola SA, FIMI; Saronno VA
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 500 x 390 x 280 mm / 19.7 x 15.4 x 11 inch
Notes

Variante nota con elenco valvole: ACH1 RENS1284 AB1 RENS 1284 WE30 WE30 WE52.

Source of data Il Manuale del Radiomeccanico

Model page created by Ernst Röggla. See "Data change" for further contributors.
