530; Phonola SA, FIMI; (ID = 636145) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  Italy
Manufacturer / Brand:  Phonola SA, FIMI; Saronno (VA)
Year: 1940/1941 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: EK2 EF9 EBC3 EL3 WE54
Main principle Super-Heterodyne (Super in general); ZF/IF 470 kHz
Wave bands Broadcast and Short Wave (SW).
Details Record Player (not changer)
Power type and voltage Alternating Current supply (AC) / 100-270 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 3.7 W (unknown quality)
from Radiomuseum.org Model: 530 - Phonola SA, FIMI; Saronno VA
Material Wooden case
Notes Radiofonografo. Serie Neosinto
Consuma: 80 Watt
Literature/Schematics (1) D.E.Ravalico, Schemario degli Apparecchi Radio, IV Edizione, 1950, Hoepli

Model page created by Eduard Abfalterer. See "Data change" for further contributors.
