For model Roma, Phonola SA, FIMI; Saronno (VA)

Country:  Italy
Manufacturer / Brand:  Phonola SA, FIMI; Saronno (VA)
Year: 1939/1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: ECH3 EBL1 WE54
Main principle Super-Heterodyne (Super in general); ZF/IF 470 kHz; Reflex
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 110-220 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 17 cm = 6.7 inch
Power out
from Radiomuseum.org Model: Roma - Phonola SA, FIMI; Saronno VA
Material Wooden case
Shape Tablemodel, Mantel/Midget/Compact up to 14" width, but not a Portable (See power data. Sometimes with handle but for mains only).
Dimensions (WHD) 300 x 245 x 190 mm / 11.8 x 9.6 x 7.5 inch
Notes Phonola Radio Roma. Ricevitore popolare di regime, venduta a prezzo politico su disposizioni governative.
Collectors' prices
Source of data Guida Pratica Antique Radio III (2000)

Model page created by Alessandro De Poi. See "Data change" for further contributors.
