• Country
• Germany

• Manufacturer / Brand
• Phywe, Physikalische Werkstätten A.G.; Göttingen

• Year
• 1954 ??

• Category
• Teaching aids-material

• Radiomuseum.org ID
• 164434

Click on the schematic thumbnail to request the schematic as a free document.

• Wave bands
• - without

• Power type and voltage
• No Power needed

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Metal case

• from Radiomuseum.org
• Model: Lautsprecherplatte LS - Phywe, Physikalische

• Dimensions (WHD)
• 320 x 28 x 105 mm / 12.6 x 1.1 x 4.1 inch

• Notes

• Modul aus Funk-Lehrgerät mit eingebautem Lautsprecher. Eingänge mit 5 kΩ bzw.11 kΩ Eingangswiderstand.

• Net weight (2.2 lb = 1 kg)
• 3 kg / 6 lb 9.7 oz (6.608 lb)

• Author
• Model page created by Rudolf Osterkamp. See "Data change" for further contributors.
