B-1 ; Pilot Electric Mfg. (ID = 881792) Radio
Pilot Electric Mfg.: B-1 [Radio] ID = 881792 933x638
Select picture or schematic to display from thumbnails on the right and click for download.
For model B-1, Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY):
By courtesy of guest Tom Hart, Dedham, MA, USA.

Country:  United States of America (USA)
Manufacturer / Brand:  Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY)
alternative name

Pilot Radio & Television || Pilot Radio and Tube || Pilot Radio Corporation
Year: 1940 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 12SK7 12SA7 12SK7 12SQ7 35L6GT 35Z5GT
Main principle Super-Heterodyne (Super in general); ZF/IF 455 kHz; 1 AF stage(s); Export model
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage AC/DC-set / 117; 130; 150; 230 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 5 inch = 12.7 cm
Power out
from Radiomuseum.org Model: B-1 - Pilot Electric Mfg. Co. Radio
Material Bakelite case
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 380 x 220 x 160 mm / 15 x 8.7 x 6.3 inch
Notes Built-in loop antenna; a special resistance line cord is used for 220 V mains supply.
Aparelho exportado para Portugal durante a II Guerra Mundial.
Net weight (2.2 lb = 1 kg) 5 kg / 11 lb 0.2 oz (11.013 lb)
Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 12 = ca. 1941 and before
Mentioned in Rider's Perpetual, Volume 13 = 1942 and before
Literature/Schematics (1) Beitman Radio Diagrams, Vol. 04, 1941
