FM Multiplexer 200

FM Multiplexer 200; Pilot Electric Mfg. (ID = 1279189) mod-past25 FM Multiplexer 200; Pilot Electric Mfg. (ID = 1279190) mod-past25
FM Multiplexer 200; Pilot Electric Mfg. (ID = 1279191) mod-past25 FM Multiplexer 200; Pilot Electric Mfg. (ID = 1279192) mod-past25
FM Multiplexer 200; Pilot Electric Mfg. (ID = 1279193) mod-past25 FM Multiplexer 200; Pilot Electric Mfg. (ID = 1279194) mod-past25
Use red slider bar for more.
FM Multiplexer 200; Pilot Electric Mfg. (ID = 1279189) mod-past25
Pilot Electric Mfg.: FM Multiplexer 200 [mod-past25] ID = 1279189 624x240
Select picture or schematic to display from thumbnails on the right and click for download.
For model FM Multiplexer 200, Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY):
aus ebay, #380437653294, Verkäufer myostuff

Country:  United States of America (USA)
Manufacturer / Brand:  Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY)
alternative name

Pilot Radio & Television || Pilot Radio and Tube || Pilot Radio Corporation
Year: 1961 ? Category: Radio module post 1925 (not a part, not a key)
Valves / Tubes 4: 12AT7 12AT7 12AU7 6X4
Wave bands - without
Details
Power type and voltage Alternating Current supply (AC) / 105-120 Volt
Loudspeaker - For headphones or amp.
Power out
from Radiomuseum.org Model: FM Multiplexer 200 - Pilot Electric Mfg. Co. Radio
Material Metal case
Shape Chassis only or for «building in»
Dimensions (WHD) 3 x 5 x 12.75 inch / 76 x 127 x 324 mm
Notes

Pilot Radio Corp. FM Multiplexer model 200; with Multiplex Indicator output.
