For model G-508, Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY):
Retouched version of Bill Moore Photo

Country:  United States of America (USA)
Manufacturer / Brand:  Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY)
alternative name

Pilot Radio & Television || Pilot Radio and Tube || Pilot Radio Corporation
Year: 1945 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 10: 6K7 6L7 6K7 6B8 6E5 6J7 6Q7 6V6G 6V6G 5U4G
Main principle Superhet with RF-stage; ZF/IF 456 kHz
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 115; 125; 150; 220; 240 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil) / Ø 12 inch = 30.5 cm
Power out
from Radiomuseum.org Model: G-508 - Pilot Electric Mfg. Co. Radio
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes
External source of data E. Erb 3-907007-36-0
Circuit diagram reference Die «Thali Schemasammlung» führt das Modell.
Literature/Schematics (1) Rider's Perpetual, Volume 19 = covering late 1948 to early 1949 (Copyright 1949)
