T-530 Series

T-530 Series ; Pilot Electric Mfg. (ID = 356415) Radio

T-530 Series ; Pilot Electric Mfg. (ID = 356416) Radio

T-530 Series ; Pilot Electric Mfg. (ID = 356417) Radio

T-530 Series ; Pilot Electric Mfg. (ID = 356418) Radio

T-530 Series ; Pilot Electric Mfg. (ID = 599207) Radio

T-530 Series ; Pilot Electric Mfg. (ID = 599208) Radio

T-530 Series ; Pilot Electric Mfg. (ID = 599209) Radio

T-530 Series ; Pilot Electric Mfg. (ID = 599210) Radio

T-530 Series ; Pilot Electric Mfg. (ID = 599211) Radio

T-530 Series ; Pilot Electric Mfg. (ID = 599212) Radio
T-530 Series ; Pilot Electric Mfg. (ID = 599206) Radio T-530 Series ; Pilot Electric Mfg. (ID = 2389205) Radio
T-530 Series ; Pilot Electric Mfg. (ID = 2389206) Radio T-530 Series ; Pilot Electric Mfg. (ID = 2389208) Radio
Use red slider bar for more.
T-530 Series ; Pilot Electric Mfg. (ID = 599206) Radio
Pilot Electric Mfg.: T-530 Series [Radio] ID = 599206 788x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model T-530 Series, Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY):
SAMS Photofact

Country:  United States of America (USA)
Manufacturer / Brand:  Pilot Electric Mfg. Co. (Radio Corp.); Brooklyn (NY)
alternative name

Pilot Radio & Television || Pilot Radio and Tube || Pilot Radio Corporation
Year: 1946/1947 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 8: 6SB7Y 6SG7 6SG7 6SJ7 6H6 6SJ7 25L6GT 25Z6GT
Main principle Super-Heterodyne (Super in general); ZF/IF 455/1070 kHz
Wave bands Broadcast, more than 2 SW bands plus FM or UHF.
Details
Power type and voltage AC/DC-set / 110 - 125 or 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 7.5 inch = 19.1 cm
Power out
from Radiomuseum.org Model: T-530 Series - Pilot Electric Mfg. Co. Radio
Material Wooden case
Shape Tablemodel, with any shape - general.
Notes The Pilot model T-530 an AC-DC Operated Multiband Superheterodyne Receiver.
Collectors' prices
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 18 = 1949 and before
Literature/Schematics (1) Photofact Folder, Howard W. SAMS (Date: Jan 1947, Set 12, Folder 472-24)
