AM SSB Mobile Transceiver SS 40
Polmar; Milano
- Country
- Italy
- Manufacturer / Brand
- Polmar; Milano
- Year
- 1970 ??
- Category
- Citizen Band Equipment
- Radiomuseum.org ID
- 309953
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Transceiver
- Wave bands
- Short Wave (SW only)
- Power type and voltage
- Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
- Loudspeaker
- Presumably Dynamic Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
- Material
- Metal case
- from Radiomuseum.org
- Model: AM SSB Mobile Transceiver SS 40 - Polmar; Milano
- Shape
- Chassis only or for «building in»
- Dimensions (WHD)
- 197 x 280 x 62 mm / 7.8 x 11 x 2.4 inch
- Notes
-
controllo volume/squelch/RF Gain/Clarifier - S/Meter + Wattmetro analogico a lancetta retroilluminato - commutatore AM/USB/LSB - display rosso a 2 digit - commutatore ANB/ANL - tone/low - CB/PA - CH9/off - led verde modulazione - led rossi AM/USB/LSB - staffa di montaggio - microfono preamplificato con gain regolabile - impedenza di antenna 50 Ω - potenza RF: 5 watt AM - 12 watt SSB - 120 canali (40 AM/40 USB/40 LSB) - presa per altoparlante esterno - presa per altoparlante PA.
Made in Korea
- Net weight (2.2 lb = 1 kg)
- 3.2 kg / 7 lb 0.8 oz (7.048 lb)
- Author
- Model page created by Edoardo Sigismondo. See "Data change" for further contributors.
