AC Superhet Radio Kit Bakelite

Premier Radio Co. Ltd.; London

  • Year
  • 1954 ??
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 126003

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 4
  • Main principle
  • Superheterodyne (common); 2 AF stage(s)
  • Tuned circuits
  • 6 AM circuit(s)
  • Wave bands
  • Broadcast, Long Wave and Short Wave.
  • Power type and voltage
  • Alternating Current supply (AC) / 200-250 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
  • Material
  • Bakelite case
  • from Radiomuseum.org
  • Model: AC Superhet Radio Kit [Bakelite] - Premier Radio Co. Ltd.; London
  • Dimensions (WHD)
  • 11.5 x 6.5 x 5.5 inch / 292 x 165 x 140 mm
  • Notes
  • Same case as the Pilot "Little Meastro" which was used by several kit manufacturers such as "Occasional 4" or "Atomic" or "Meteor III" or "Ocean Hopper", as late as 1959.
  • Literature/Schematics (1)
  • - - Manufacturers Literature
  • Author
  • Model page created by Keith Staines. See "Data change" for further contributors.
