Ranchero MR-2 (R16-04A) Ch= R16-1A

Ranchero MR-2 Ch= R16-1A; Pye Industries Ltd (ID = 1889747) Radio Ranchero MR-2 Ch= R16-1A; Pye Industries Ltd (ID = 1889748) Radio
Ranchero MR-2 Ch= R16-1A; Pye Industries Ltd (ID = 1889749) Radio Ranchero MR-2 Ch= R16-1A; Pye Industries Ltd (ID = 1889750) Radio
Ranchero MR-2 Ch= R16-1A; Pye Industries Ltd (ID = 1889751) Radio Ranchero MR-2 Ch= R16-1A; Pye Industries Ltd (ID = 1889752) Radio
Ranchero MR-2 Ch= R16-1A; Pye Industries Ltd (ID = 1889753) Radio Ranchero MR-2 Ch= R16-1A; Pye Industries Ltd (ID = 1912714) Radio
Use red slider bar for more.
Ranchero MR-2 Ch= R16-1A; Pye Industries Ltd (ID = 1889747) Radio
Pye Industries Ltd: Ranchero MR-2 Ch= R16-1A [Radio] ID = 1889747 1400x739
Select picture or schematic to display from thumbnails on the right and click for download.
For model Ranchero MR-2 (R16-04A) Ch= R16-1A, Pye Industries Ltd Australia; Marrickville

Country:  Australia
Manufacturer / Brand:  Pye Industries Ltd Australia; Marrickville
Year: 1959–1961 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: 6BE6 6BA6 6AV6 6AQ5 6V4
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 200-260 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: Ranchero MR-2 Ch= R16-1A - Pye Industries Ltd Australia;
Material Modern plastics (no Bakelite or Catalin)
Shape Book-shelf unit.
Dimensions (WHD) 13.5 x 5.75 x 6 inch / 343 x 146 x 152 mm
Notes

Pye MR2

A five-valve B/C mantel radio using printed circuitry and housed in a cabinet coloured coral, primrose, jade, charcoal or white with 24 carat gold plated-plated trim.

Features: built-in ferrite rod aerial; tuning range 535 - 1650 kC/s (kHz); 4" speaker. Controls: tuning, volume/on-off. (MINGAY'S PRICE SERVICE)

See also Ranchero Model MR-1  & Executive TM6 Models R15-2A, R15-2B & R15-2C

See advert HRSA Radio Waves 134, October 2015, Rear Cover  .

Net weight (2.2 lb = 1 kg) 3.9 kg / 8 lb 9.4 oz (8.59 lb)
Price in first year of sale 25.20 AUS £
Mentioned in Mingay's Radio Electrical Weekly Price Service (REWPS) (Feb 1960 to Aug 1961.)
Literature/Schematics (1) - - Manufacturers Literature (Pye Radio Service Data.)
Literature/Schematics (2) J.R. Publications Radio Service Handbook (R.V. Series Vol. 1, 1963, Page P212.)

Model page created by Kenneth Walker. See "Data change" for further contributors.
