For model LV30, Pye Ltd., Radio Works; Cambridge

Country:  Great Britain (UK)
Manufacturer / Brand:  Pye Ltd., Radio Works; Cambridge
Year: 1950 Category: Television Receiver (TV) or Monitor
Valves / Tubes 15: EF80 EF80 EF80 EB91 EF80 EF80 PL38 EY51 PZ30 EF80 EB91 ECL80 EB91 ECL80 MW22-14 or MW22-16 or MW22-18
Main principle TRF (Tuned-Radio-Frequency but use of regeneration unknown)
Wave bands Wave Bands given in the notes.
Details
Power type and voltage AC/DC-set / 200-250 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet.
Power out
from Radiomuseum.org Model: LV30 - Pye Ltd., Radio Works;
Material Wooden case
Shape Tablemodel, low profile (big size).
Notes Pye LV30;
22 cm/9" (8" x 6" visible size) round CRT "Black Screen" B/W 405 lines TV with single channel GB VHF band I tuner, fix aligned to London TV station channel 1, sensitivity 65 µV/ sound 25 µV, compare with most similar BV30 Birmingham & MV30 Holme Moss sets, 100 - 125 W power consumption. Each tube type listed once only.
Source of data -- Original-techn. papers.
Mentioned in (GB) Advert "The Wireless and Electrical Trader" Dec 23, 1950
Literature/Schematics (1) Trader Service Sheet (suppl. of Wireless & El. Trader, etc.) (988/T11)

Model page created by a member from A. See "Data change" for further contributors.
