PE230

PE230; Pye Ltd., Radio (ID = 2388811) Radio PE230; Pye Ltd., Radio (ID = 1289830) Radio
PE230; Pye Ltd., Radio (ID = 1289912) Radio PE230; Pye Ltd., Radio (ID = 1290231) Radio
PE230; Pye Ltd., Radio (ID = 1290232) Radio PE230; Pye Ltd., Radio (ID = 1290233) Radio
PE230; Pye Ltd., Radio (ID = 1290234) Radio
Use red slider bar for more.
PE230; Pye Ltd., Radio (ID = 2388811) Radio
Pye Ltd., Radio: PE230 [Radio] ID = 2388811 1400x818
Select picture or schematic to display from thumbnails on the right and click for download.
For model PE230, Pye Ltd., Radio Works; Cambridge

Country:  Great Britain (UK)
Manufacturer / Brand:  Pye Ltd., Radio Works; Cambridge
Year: 1960 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: ECH81 EF89 EBC81 EL84 EM84 EZ80
Main principle Superheterodyne (common); ZF/IF 470 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast, Long Wave and more than two Short Wave bands.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220; 250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 inch = 20.3 cm
Power out 4 W (unknown quality)
from Radiomuseum.org Model: PE230 - Pye Ltd., Radio Works;
Material Wooden case
Shape Tablemodel with Push Buttons.
Dimensions (WHD) 495 x 300 x 190 mm / 19.5 x 11.8 x 7.5 inch
Price in first year of sale 29.00 £?

Model page created by João Luis Mendes Colaço. See "Data change" for further contributors.
