PE70B

PE70B; Pye Ltd., Radio (ID = 577427) Radio PE70B; Pye Ltd., Radio (ID = 577437) Radio
PE70B; Pye Ltd., Radio (ID = 577431) Radio PE70B; Pye Ltd., Radio (ID = 577428) Radio
PE70B; Pye Ltd., Radio (ID = 577429) Radio PE70B; Pye Ltd., Radio (ID = 577430) Radio
PE70B; Pye Ltd., Radio (ID = 577440) Radio PE70B; Pye Ltd., Radio (ID = 577442) Radio
PE70B; Pye Ltd., Radio (ID = 805421) Radio
Use red slider bar for more.
PE70B; Pye Ltd., Radio (ID = 577427) Radio
Pye Ltd., Radio: PE70B [Radio] ID = 577427 797x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model PE70B, Pye Ltd., Radio Works; Cambridge

Country:  Great Britain (UK)
Manufacturer / Brand:  Pye Ltd., Radio Works; Cambridge
Year: 1952 ? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: DK92 DF91 DAF91 DL94
schematic requested
Main principle Superheterodyne (common)
Wave bands Broadcast plus 2 Short Wave bands.
Details
Power type and voltage Storage and/or dry batteries / 90-120 & 1.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out
from Radiomuseum.org Model: PE70B - Pye Ltd., Radio Works;
Material Bakelite case
Shape Tablemodel without push buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 300 x 220 x 160 mm / 11.8 x 8.7 x 6.3 inch
Net weight (2.2 lb = 1 kg) 3.8 kg / 8 lb 5.9 oz (8.37 lb)

Model page created by Adamantios Nikolaidis Wentzelopoulos. See "Data change" for further contributors.



All listed radios etc. from Pye Ltd., Radio Works; Cambridge
Here you find 578 models, 422 with images and 335 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
