unknown export receiver

unknown export receiver ; Pye Ltd., Radio (ID = 443831) Radio unknown export receiver ; Pye Ltd., Radio (ID = 443832) Radio
unknown export receiver ; Pye Ltd., Radio (ID = 443830) Radio
Use red slider bar for more.
unknown export receiver ; Pye Ltd., Radio (ID = 443831) Radio
Pye Ltd., Radio: unknown export receiver [Radio] ID = 443831 858x570
Select picture or schematic to display from thumbnails on the right and click for download.
For model unknown export receiver, Pye Ltd., Radio Works; Cambridge

Country:  Great Britain (UK)
Manufacturer / Brand:  Pye Ltd., Radio Works; Cambridge
Year: 1954 ?? Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: UCH42 UAF42 UL41 UY41
Main principle Super-Heterodyne (Super in general); Export model
Wave bands Broadcast plus more than 2 Short Wave bands.
Details
Power type and voltage AC/DC-set / 110-160; 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: unknown export receiver - Pye Ltd., Radio Works;
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel, low profile (big size).
Notes 5 bands: BC; SW 3.2 - 7.5 MHz; 31 m; 25 m; 19 m.
Source of data -- Collector info (Sammler)

Model page created by Dimitris Dalipis. See "Data change" for further contributors.



All listed radios etc. from Pye Ltd., Radio Works; Cambridge
Here you find 560 models, 402 with images and 323 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
