AR2757

AR2757; QUELLE GmbH (ID = 913468) Car Radio

AR2757; QUELLE GmbH (ID = 913469) Car Radio

AR2757; QUELLE GmbH (ID = 913470) Car Radio

AR2757; QUELLE GmbH (ID = 913471) Car Radio

AR2757; QUELLE GmbH (ID = 913472) Car Radio

AR2757; QUELLE GmbH (ID = 913473) Car Radio

AR2757; QUELLE GmbH (ID = 913474) Car Radio
AR2757; QUELLE GmbH (ID = 913467) Car Radio
Use red slider bar for more.
AR2757; QUELLE GmbH (ID = 913467) Car Radio
QUELLE GmbH: AR2757 [Car Radio] ID = 913467 869x472
Select picture or schematic to display from thumbnails on the right and click for download.
For model AR2757, QUELLE GmbH (Universum); Fürth und Nürnberg:
Aus Quelle-Service-Manual

Country:  Germany
Manufacturer / Brand:  QUELLE GmbH (Universum); Fürth und Nürnberg
Year: 1974 ? Category: Car Radio, perhaps also + sound player/recorder
Semiconductors (the count is only for transistors) 14:
Main principle Superheterodyne (common); ZF/IF 460/10700 kHz
Wave bands Broadcast, Long Wave, Short Wave plus FM or UHF.
Details
Power type and voltage Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt
Loudspeaker - This model requires external speaker(s).
Power out 6 W (unknown quality)
from Radiomuseum.org Model: AR2757 - QUELLE GmbH Universum; Fürth
Material Metal case
Shape Chassis only or for «building in»
Source of data -- Original-techn. papers.

Model page created by Heiko zur Mühlen. See "Data change" for further contributors.
