electronic clock radio W1053U

electronic clock radio W1053U; QUELLE GmbH (ID = 2406307) Radio electronic clock radio W1053U; QUELLE GmbH (ID = 2406308) Radio
electronic clock radio W1053U; QUELLE GmbH (ID = 2406310) Radio electronic clock radio W1053U; QUELLE GmbH (ID = 2406311) Radio
electronic clock radio W1053U; QUELLE GmbH (ID = 2406306) Radio electronic clock radio W1053U; QUELLE GmbH (ID = 2406309) Radio
Use red slider bar for more.
electronic clock radio W1053U; QUELLE GmbH (ID = 2406307) Radio
QUELLE GmbH: electronic clock radio W1053U [Radio] ID = 2406307 1400x690
Select picture or schematic to display from thumbnails on the right and click for download.
For model electronic clock radio W1053U, QUELLE GmbH (Universum); Fürth und Nürnberg

Country:  Germany
Manufacturer / Brand:  QUELLE GmbH (Universum); Fürth und Nürnberg
Year: 1972 Category: Broadcast Receiver - or past WW2 Tuner
Main principle Superheterodyne (common)
Wave bands Broadcast (BC) and FM or UHF.
Details Radio with other functions
Power type and voltage Alternating Current supply (AC) / 220 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: electronic clock radio W1053U - QUELLE GmbH Universum; Fürth
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Clock ((Alarm-) Clock Radio).
Dimensions (WHD) 210 x 150 x 44 mm / 8.3 x 5.9 x 1.7 inch
Notes



Universum W1053U  electronic clock radio baugleich mit E-2 produced by Realtone, Hongkong ( sister company of Realtone, Japan ) in early 1970 with green or blue fluorescent display. Various cabinet colors known.







Net weight (2.2 lb = 1 kg) 1 kg / 2 lb 3.2 oz (2.203 lb)

Model page created by Eckhard Wegner. See "Data change" for further contributors.
