Portable Radio Cassette Recorder CTR 1032 Best. Nr. 853.120 4
QUELLE GmbH (Universum); Fürth und Nürnberg
- Country
- Germany
- Manufacturer / Brand
- QUELLE GmbH (Universum); Fürth und Nürnberg
- Year
- 1990 ??
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 240701
- Number of Transistors
- Semiconductors present.
- Semiconductors
- Main principle
- Superheterodyne (common)
- Wave bands
- Broadcast (BC) and FM or UHF.
- Details
- Cassette-Recorder or -Player
- Power type and voltage
- Line / Batteries (any type) / 230 / R20: 4 x 1,5 Volt
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 8 cm = 3.1 inch
- Material
- Various materials
- from Radiomuseum.org
- Model: Portable Radio Cassette Recorder CTR 1032 Best. Nr. 853.120 4 - QUELLE GmbH Universum; Fürth
- Shape
- Portable set > 8 inch (also usable without mains)
- Dimensions (WHD)
- 302 x 139 x 97 mm / 11.9 x 5.5 x 3.8 inch
- Notes
-
2-Band-Radio-Cassette-Recorder; FM-Empfang über Teleskopantenne (61cm); AM-Empfang über eingebaute Ferritantenne; Anschluss "Phones" 3,5mm Klinkenbuchse; eingebautes Mikrofon; Umschalter "Beat Cut 1 und 2" auf der Geräterückseite.
- Net weight (2.2 lb = 1 kg)
- 1.270 kg / 2 lb 12.8 oz (2.797 lb)
- Author
- Model page created by Michael Mischke. See "Data change" for further contributors.
