• Country
• Germany

• Manufacturer / Brand
• QUELLE GmbH (Universum); Fürth und Nürnberg

• Year
• 1978 ??

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 286471

• Number of Transistors
• Semiconductors present.

• Semiconductors
• LA1210 TBA810

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, (BC) Long Wave (LW), 2 x SW and FM or UHF.

• Details
• Cassette-Recorder or -Player

• Power type and voltage
• Line / Batteries (any type) / 220 / D: 6x1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Universum CTR 2389 - QUELLE GmbH Universum; Fürth

• Shape
• Portable set > 8 inch (also usable without mains)

• Dimensions (WHD)
• 410 x 240 x 95 mm / 16.1 x 9.4 x 3.7 inch

• Notes

•


• Author
• Model page created by Ottmar Lauth. See "Data change" for further contributors.
