• Country
• Germany

• Manufacturer / Brand
• QUELLE GmbH (Universum); Fürth und Nürnberg

• Year
• 1990 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 138780

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 23

• Semiconductors

• Main principle
• Superhet, double/triple conversion

• Wave bands
• Broadcast, Long Wave, Short Wave plus FM or UHF.

• Power type and voltage
• Dry Batteries / 4 x 1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 6.5 cm = 2.6 inch

• Power out
• 0.5 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: Universum TR 3044 St - QUELLE GmbH Universum; Fürth

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 180 x 110 x 30 mm / 7.1 x 4.3 x 1.2 inch

• Notes

• Weltempfänger

  • PLL-Abstimmung
  • Digitaluhr
  • Sendersuchlauf
  • 25 Speicherplätze
  • Sleepfunktion
  • Displaybeleuchtung
  • 4 ICs
  • Zwei Silberoxid-Knopfzellen (z.B. G13) für PLL-System
  • KW 5,8 - 15,5 MHz (49 - 19 m)

• Net weight (2.2 lb = 1 kg)
• 0.6 kg / 1 lb 5.1 oz (1.322 lb)

• Source of data
• -- Original-techn. papers.

• Author
• Model page created by a member from D. See "Data change" for further contributors.
