Digital Frequency Meter SA-520B

Digital Frequency Meter SA-520B; Racal Engineering (ID = 1011587) Equipment Digital Frequency Meter SA-520B; Racal Engineering (ID = 1011588) Equipment
Digital Frequency Meter SA-520B; Racal Engineering (ID = 1011589) Equipment Digital Frequency Meter SA-520B; Racal Engineering (ID = 1011590) Equipment
Digital Frequency Meter SA-520B; Racal Engineering (ID = 1011591) Equipment Digital Frequency Meter SA-520B; Racal Engineering (ID = 1011592) Equipment
Digital Frequency Meter SA-520B; Racal Engineering (ID = 2017642) Equipment Digital Frequency Meter SA-520B; Racal Engineering (ID = 2017643) Equipment
Digital Frequency Meter SA-520B; Racal Engineering (ID = 2017644) Equipment Digital Frequency Meter SA-520B; Racal Engineering (ID = 2017645) Equipment
Use red slider bar for more.
Digital Frequency Meter SA-520B; Racal Engineering (ID = 1011587) Equipment
Racal Engineering: Digital Frequency Meter SA-520B [Equipment] ID = 1011587 912x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model Digital Frequency Meter SA-520B, Racal Engineering (Racal Instruments) Ltd., Bracknell

Country:  Great Britain (UK)
Manufacturer / Brand:  Racal Engineering (Racal Instruments) Ltd., Bracknell
Year: 1966 Category: Service- or Lab Equipment
Semiconductors (the count is only for transistors) Semiconductors present.
Wave bands - without
Details
Power type and voltage Line plus power jack, mostly with battery or storage battery / 45-60 Hz, 115; 200; 220; 240 / 2 x 15 Volt
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Digital Frequency Meter SA-520B - Racal Engineering Racal
Material Metal case
Shape Tablemodel without bush buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 194 x 165 x 184 mm / 7.6 x 6.5 x 7.2 inch
Notes

Frequenz-Periodendauer-Meßgerät mit 4 Ziffernanzeigen.
Außergewöhnliches, sehr aufwändiges Anzeigeverfahren: mit Lichtleitern aus verbundenen zylindrischen Stäbchen sind Ziffern von 0 bis 9 nachgebildet, welche, durch Glühlämpchen beleuchtet, eine punktformige Ziffern-Darstellung zeigen. Die Ansteuerung der Lämpchen erfolgt durch Transistoren wie beim Vorgängermodell SA-520 (siehe Schaltunterlagen bei SA-520).
Portabler Betrieb mit externen Batterien (+/-15Volt) möglich.

See also SA-520.

Net weight (2.2 lb = 1 kg) 3.2 kg / 7 lb 0.8 oz (7.048 lb)

Model page created by a member from D. See "Data change" for further contributors.
