SSB Radiotelephone TRA55B

SSB Radiotelephone TRA55B; Racal Engineering (ID = 2585466) Commercial TRX SSB Radiotelephone TRA55B; Racal Engineering (ID = 2585467) Commercial TRX
SSB Radiotelephone TRA55B; Racal Engineering (ID = 2585468) Commercial TRX SSB Radiotelephone TRA55B; Racal Engineering (ID = 2586054) Commercial TRX
SSB Radiotelephone TRA55B; Racal Engineering (ID = 2586055) Commercial TRX SSB Radiotelephone TRA55B; Racal Engineering (ID = 2586056) Commercial TRX
SSB Radiotelephone TRA55B; Racal Engineering (ID = 2586057) Commercial TRX
Use red slider bar for more.
SSB Radiotelephone TRA55B; Racal Engineering (ID = 2585466) Commercial TRX
Racal Engineering: SSB Radiotelephone TRA55B [Commercial TRX] ID = 2585466 1400x814
Select picture or schematic to display from thumbnails on the right and click for download.
For model SSB Radiotelephone TRA55B, Racal Engineering (Racal Instruments) Ltd., Bracknell:
Racal TRA55B front. Photo credit Theo Moller.

Country:  Great Britain (UK)
Manufacturer / Brand:  Racal Engineering (Racal Instruments) Ltd., Bracknell
Year: 1958 ? Category: Commercial Transmitter & Receiver (TRX not Amateur)
Valves / Tubes 20: 12AT7 CV6091 6AQ5 6AL5 5R4GY 5R4GY 6AU6 6AL5 6AL5 6AU6 6AS6 6BA6 6AU6 6AS6 CV455 6BA6 CV455 TT21 TT21 6AL5
Main principle Transceiver; ZF/IF 1400 kHz
Wave bands Short Wave (SW only)
Details
Power type and voltage Alternating Current supply (AC) / 100-125 or 200-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: SSB Radiotelephone TRA55B - Racal Engineering Racal
Material Metal case
Shape Boatanchor (heavy military or commercial set >20 kg).
Dimensions (WHD) 19.25 x 10.5 x 18 inch / 489 x 267 x 457 mm
Notes

4 channel, crystal locked SSB transeiver.

The TRA55B SSB transceiver is a later version of the TRA55.

Mentioned in -- Collector info (Sammler)

Model page created by Gary Cowans. See "Data change" for further contributors.



All listed radios etc. from Racal Engineering (Racal Instruments) Ltd., Bracknell
Here you find 105 models, 51 with images and 11 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
