Super-But 1954

Super-But ; Radialva, Véchambre (ID = 525685) Radio
Super-But ; Radialva, Véchambre (ID = 1449235) Radio Super-But ; Radialva, Véchambre (ID = 1449236) Radio
Super-But ; Radialva, Véchambre (ID = 328976) Radio Super-But ; Radialva, Véchambre (ID = 328977) Radio
Super-But ; Radialva, Véchambre (ID = 328978) Radio Super-But ; Radialva, Véchambre (ID = 328979) Radio
Super-But ; Radialva, Véchambre (ID = 328980) Radio Super-But ; Radialva, Véchambre (ID = 525684) Radio
Super-But ; Radialva, Véchambre (ID = 1005831) Radio Super-But ; Radialva, Véchambre (ID = 1156053) Radio
Use red slider bar for more.
Super-But ; Radialva, Véchambre (ID = 1449235) Radio
Radialva, Véchambre: Super-But [Radio] ID = 1449235 933x634
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super-But 1954, Radialva, Véchambre Frères; Asnières, Courbevoie, Saint-Denis

Country:  France
Manufacturer / Brand:  Radialva, Véchambre Frères; Asnières, Courbevoie, Saint-Denis
Year: 1953/1954 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: ECH81 EBF80 EBF80 EL84 EZ80
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)
Power out
from Radiomuseum.org Model: Super-But [1954] - Radialva, Véchambre Frères;
Material Bakelite case
Shape Tablemodel without bush buttons, Mantel/Midget/Compact up to 14
Dimensions (WHD) 350 x 202 x 180 mm / 13.8 x 8 x 7.1 inch
Notes

4 gammes d'ondes : GO de 1000 à 1900 m, PO de 190 à 580 m, OC1 de 26 à 50 m, OC2 de 13 à 26 m. Cadre incorporé orientable. Commutation automatique cadre-antenne.

Net weight (2.2 lb = 1 kg) 5.9 kg / 12 lb 15.9 oz (12.996 lb)
Mentioned in -- Original prospect or advert (Gamme 1954)
Literature/Schematics (2) -- Schematic

Model page created by Pietro Gallia. See "Data change" for further contributors.
