• Country
• Belgium

• Manufacturer / Brand
• Bell Telephone Mfg. Co. (Radiobell); Antwerp

• Year
• 1936/1937

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 189835

• • Brand: Radiobell

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Tubes
• 5

• Valves / Tubes
• EK2 EF5 EB4 EL3 EZ2

• Main principle
• Superheterodyne (common); ZF/IF 445 kHz

• Tuned circuits
• 6 AM circuit(s)

• Wave bands
• Broadcast and LongWave in ONE range.

• Power type and voltage
• Alternating Current supply (AC) / 110; 135; 150; 220; 250 Volt

• Loudspeaker
• Electro Magnetic Dynamic LS (moving-coil with field excitation coil)

• Material
• Wooden case

• from Radiomuseum.org
• Model: Radiobell 374 - Bell Telephone Mfg. Co.

• Shape
• Tablemodel, low profile (big size).

• Notes
• Codex J.V. AS4626

• Price in first year of sale
• 1,990.00 BFR

• Author
• Model page created by Getulio Jimenez-Gomez. See "Data change" for further contributors.

• Other Models

• Here you find 281 models, 242 with images and 113 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
