Teletester (Griddipper)

Radio-Contrôle; Lyon

  • Year
  • 1959
  • Category
  • Service- or Lab Equipment
  • Radiomuseum.org ID
  • 171746

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Tubes
  • 2
  • Number of Transistors
  • 1
  • Semiconductors
  • OC72
  • Wave bands
  • Wave Bands given in the notes.
  • Power type and voltage
  • Alternating Current supply (AC) / 110; 130; 220 Volt
  • Loudspeaker
  • - - No sound reproduction output.
  • Material
  • Metal case
  • from Radiomuseum.org
  • Model: Teletester - Radio-Contrôle; Lyon
  • Dimensions (WHD)
  • 200 x 65 x 65 mm / 7.9 x 2.6 x 2.6 inch
  • Notes
  • Griddipper with AM and FM modulation and internal AF generator.
    Equipped with 7 coils covering from 2 MHz to 250 MHz.
    It has a socket for testing Xtals.

    Adaptateur pour la mesure de capacité de 0 à 1600pF.
    Adaptateur pour la mesure de tension HF (Voltmètre électronique).
    Possède un redresseur HT au sélénium E250C40

  • Net weight (2.2 lb = 1 kg)
  • 0.980 kg / 2 lb 2.5 oz (2.159 lb)
  • Price in first year of sale
  • 31,700.00 F
  • Literature/Schematics (1)
  • - - Manufacturers Literature
