• Country
• Mozambique

• Manufacturer / Brand
• CONRAD, Construtora Radio Electrica, Lda. Lourenco Marques, Mozambique

• Year
• 1970 ??

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 120270

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 8

• Semiconductors
• 2SA70 2SA101 2SA101 2SB173 2SB171 2SB175 2SB178 2SB178

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast plus 2 Short Wave bands.

• Power type and voltage
• Dry Batteries / 3x1,5 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 3.5 inch = 8.9 cm

• Power out
• 0.7 W (unknown quality)

• Material
• Plastics (no bakelite or catalin)

• from Radiomuseum.org
• Model: National Panasonic R-330Y - CONRAD, Construtora Radio

• Shape
• Very small Portable or Pocket-Set (Handheld) < 8 inch.

• Dimensions (WHD)
• 255 x 140 x 55 mm / 10 x 5.5 x 2.2 inch

• Notes

• Made at CONRAD - Construtora Radio Electrica, Lda manufacturing plant in Lourenco Marques, Mozambique (Portuguese Colony) under license manufacture of Matsushita Radio.

  See also R-330Y made in Japan.

• Net weight (2.2 lb = 1 kg)
• 1.5 kg / 3 lb 4.9 oz (3.304 lb)

• Author
• Model page created by Jose Duarte Costa. See "Data change" for further contributors.
