Super-octode RA563A

Super-octode RA563A; Radiola marque (ID = 2147985) Radio
Super-octode RA563A; Radiola marque (ID = 2147693) Radio Super-octode RA563A; Radiola marque (ID = 2147692) Radio
Super-octode RA563A; Radiola marque (ID = 2147697) Radio Super-octode RA563A; Radiola marque (ID = 2147696) Radio
Super-octode RA563A; Radiola marque (ID = 2147694) Radio Super-octode RA563A; Radiola marque (ID = 2147695) Radio
Super-octode RA563A; Radiola marque (ID = 2147698) Radio Super-octode RA563A; Radiola marque (ID = 2147699) Radio
Super-octode RA563A; Radiola marque (ID = 2147700) Radio Super-octode RA563A; Radiola marque (ID = 2147701) Radio
Use red slider bar for more.
Super-octode RA563A; Radiola marque (ID = 2147693) Radio
Radiola marque: Super-octode RA563A [Radio] ID = 2147693 1228x1033
Select picture or schematic to display from thumbnails on the right and click for download.
For model Super-octode RA563A, Radiola (marque)

Country:  France
Manufacturer / Brand:  Radiola (marque)
Brand

SFER
Year: 1935 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: TK1 or AK1 TF2 or AF2 TB1 or AB1 TE46 or E446 TE43H or E443H TV80 or 506
Main principle Super-Heterodyne (Super in general); ZF/IF 115 kHz
Tuned circuits 7 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110-250 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 16 cm = 6.3 inch
Power out
from Radiomuseum.org Model: Super-octode RA563A - Radiola marque
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 370 x 290 x 230 mm / 14.6 x 11.4 x 9.1 inch
Notes Das Chassis ist identisch mit Philips 510A. Loudspeaker 4281.
Source of data - - Data from my own collection

Model page created by Peter Hoddow. See "Data change" for further contributors.
