RA42U

RA42U; Radiola marque (ID = 2527474) Radio

RA42U; Radiola marque (ID = 2527475) Radio

RA42U; Radiola marque (ID = 2527476) Radio

RA42U; Radiola marque (ID = 2527477) Radio

RA42U; Radiola marque (ID = 2527478) Radio

RA42U; Radiola marque (ID = 2527479) Radio

RA42U; Radiola marque (ID = 2527480) Radio
Use red slider bar for more.
RA42U; Radiola marque (ID = 2527474) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  France
Manufacturer / Brand:  Radiola (marque)
Brand

SFER
Year: 1936/1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 5: EK2 EF5 EB4 EL3 EZ3
Main principle Superheterodyne (common); ZF/IF 128 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage AC/DC-set / 110; 125; 145; 200; 220; 245 Volt
Loudspeaker Permanent or electro-dynamic (moving coil), system not known yet. / Ø 15 cm = 5.9 inch
Power out
from Radiomuseum.org Model: RA42U - Radiola marque
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 430 x 350 x 280 mm / 16.9 x 13.8 x 11 inch
Notes

Toutes ondes. Antifading différé. Cadran de lecture en verre.

Alimentation sur CC avec vibreur.

Équivalent au Philips 456U.

Mentioned in -- Original prospect or advert (Dépliant 25.09.1936)
Literature/Schematics (2) Le grand livre de la TSF (Doctsf Ref 4592)

Model page created by John Koster. See "Data change" for further contributors.



All listed radios etc. from Radiola (marque)
Here you find 824 models, 519 with images and 268 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
