RA67A-20

RA67A-20; Radiola marque (ID = 2095618) Radio

RA67A-20; Radiola marque (ID = 2095619) Radio

RA67A-20; Radiola marque (ID = 2095620) Radio

RA67A-20; Radiola marque (ID = 2095621) Radio
RA67A-20; Radiola marque (ID = 545405) Radio RA67A-20; Radiola marque (ID = 545406) Radio
RA67A-20; Radiola marque (ID = 545407) Radio RA67A-20; Radiola marque (ID = 545408) Radio
RA67A-20; Radiola marque (ID = 545409) Radio RA67A-20; Radiola marque (ID = 545410) Radio
Use red slider bar for more.
RA67A-20; Radiola marque (ID = 545405) Radio
Radiola marque: RA67A-20 [Radio] ID = 545405 770x484
Select picture or schematic to display from thumbnails on the right and click for download.
For model RA67A-20, Radiola (marque)

Country:  France
Manufacturer / Brand:  Radiola (marque)
Brand

SFER
Year: 1936/1937 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: EK2 EF5 EBC3 EL3 EM1 EZ3
Main principle Superheterodyne (common); ZF/IF 128 kHz
Wave bands Broadcast, Long Wave and Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 125; 145; 220; 245 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 25 cm = 9.8 inch
Power out
from Radiomuseum.org Model: RA67A-20 - Radiola marque
Material Wooden case
Shape Tablemodel, low profile (big size).
Dimensions (WHD) 660 x 350 x 290 mm / 26 x 13.8 x 11.4 inch
Notes

Couplage Tellegen, séléctivité variable. Réglage visuel par Darioscope. Recherche des stations avec démultiplication automatique 2 vitesses. Boutons de tonalité et "musique-parole".

Équivalent au Philips 796A-20.

Net weight (2.2 lb = 1 kg) 19.2 kg / 42 lb 4.7 oz (42.291 lb)
Mentioned in Le grand livre de la TSF (Doctsf Ref 22893)

Model page created by Karlheinz Gützlaff. See "Data change" for further contributors.
