RA317 /00R /00L /00Z; Radiola marque (ID = 1292866) Radio
Radiola marque: RA317 /00R /00L /00Z [Radio] ID = 1292866 933x620
Select picture or schematic to display from thumbnails on the right and click for download.
For model RA317 /00R /00L /00Z, Radiola (marque)

Country:  France
Manufacturer / Brand:  Radiola (marque)
Brand

SFER
Year: 1967/1968 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: BF194 BF194 BC149 BC149 AC187 AC188 AA119 AA119 BA114
Main principle Superheterodyne (common); ZF/IF 455 kHz
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 2 x 4.5 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) - elliptical
Power out 0.5 W (unknown quality)
from Radiomuseum.org Model: RA317 /00R /00L /00Z - Radiola marque
Material Leather / canvas / plastic - over other material
Shape Portable set > 8 inch (also usable without mains)
Dimensions (WHD) 277 x 156 x 74 mm / 10.9 x 6.1 x 2.9 inch
Notes

2 gammes d'ondes: PO 1635 à 517 kHz et GO 153 à 261 kHz. Prise antenne auto pour GO uniquement. HP elliptique 155 x 103 mm, impédance 15 ohms.

Éxecutions: /00R anthracite, /00L rouge, /00Z teck.

Coffret matière plastique gainé.

Mentioned in -- Original-techn. papers.
Literature/Schematics (1) Le grand livre de la TSF (Doctsf Ref 15091)

Model page created by Jean-Louis Buton. See "Data change" for further contributors.
