For model RA-66T/00, Radiola (marque):
RA66T00

Country:  France
Manufacturer / Brand:  Radiola (marque)
Brand

SFER
Year: 1965/1966 Category: Broadcast Receiver - or past WW2 Tuner
Semiconductors (the count is only for transistors) 6: AF126 AF127 AF127 AC125 AC132 AC127 AA119 AA119 BA100
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 5 AM circuit(s)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Dry Batteries / 9 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 5 cm = 2 inch
Power out 0.15 W (unknown quality)
from Radiomuseum.org Model: RA-66T/00 - Radiola marque
Material Modern plastics (no Bakelite or Catalin)
Shape Very small Portable or Pocket-Set (Handheld) < 8 inch.
Dimensions (WHD) 69 x 101 x 30 mm / 2.7 x 4 x 1.2 inch
Notes

Chassis du L0F60 (Philips) avec cadran du L0X20 en version argent (avec les petits triangles). Housse rigide et épaisse. Boutons métal, démulti à engrenages.

Présentation:

  • 00D - ivoire
  • 00W - bleu
  • 00L - rouge

Equivalent au Philips L0F60T.

Net weight (2.2 lb = 1 kg) 0.2 kg / 0 lb 7 oz (0.441 lb)
Price in first year of sale 139.00 FF
Source of data -- Original-techn. papers.

Model page created by Olivier Palix. See "Data change" for further contributors.
