• Country
• France

• Manufacturer / Brand
• Radiola (marque)

• Year
• 1963

• Category
• Sound/Video Recorder and/or Player

• Radiomuseum.org ID
• 157569

• • Brand: SFER

• Number of Transistors
• 8

• Semiconductors
• OC58 OC58 OC75 OC44 OC75 OC74 OC26 OC79

• Main principle
• Audio-Amplification

• Wave bands
• - without

• Details
• Tape Recorder

• Power type and voltage
• Alternating Current supply (AC) / 110/127/220/245 Volt

• Loudspeaker
• Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil)

• Power out
• 2.5 W (unknown quality)

• Material
• Leather / canvas / plastic - over other material

• from Radiomuseum.org
• Model: RA- 9549 - Radiola marque

• Shape
• Tablemodel, with any shape - general.

• Dimensions (WHD)
• 420 x 390 x 210 mm / 16.5 x 15.4 x 8.3 inch

• Notes
• 4 pistes, 4 vitesses 2.45 4.75 9.5 19cm/s, diamètre des bobines 18cm, 1 moteur

• Net weight (2.2 lb = 1 kg)
• 13 kg / 28 lb 10.1 oz (28.634 lb)

• Literature/Schematics (1)
• - - Manufacturers Literature

• Author
• Model page created by Jacky Parmentier. See "Data change" for further contributors.

• Other Models

• Here you find 850 models, 559 with images and 275 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
