Sfer 28 5051 modèle 1930, 2 boutons

Sfer 28 5051; Radiola marque (ID = 1905374) Radio
Sfer 28 5051; Radiola marque (ID = 1905367) Radio Sfer 28 5051; Radiola marque (ID = 227862) Radio
Sfer 28 5051; Radiola marque (ID = 541941) Radio Sfer 28 5051; Radiola marque (ID = 541943) Radio
Sfer 28 5051; Radiola marque (ID = 541944) Radio Sfer 28 5051; Radiola marque (ID = 541945) Radio
Sfer 28 5051; Radiola marque (ID = 541946) Radio Sfer 28 5051; Radiola marque (ID = 541948) Radio
Sfer 28 5051; Radiola marque (ID = 541950) Radio Sfer 28 5051; Radiola marque (ID = 541951) Radio
Use red slider bar for more.
Sfer 28 5051; Radiola marque (ID = 1905367) Radio
Radiola marque: Sfer 28 5051 [Radio] ID = 1905367 1400x1044
Select picture or schematic to display from thumbnails on the right and click for download.
For model Sfer 28 5051 modèle 1930, 2 boutons, Radiola (marque):
SFR, Radiola; Paris; (La Radiotechnique) - Sfer 28 modèle 1930, 2 boutons - 2

Country:  France
Manufacturer / Brand:  Radiola (marque)
Brand

SFER
Year: 1929–1931 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: R43 R75 R75 R78 R75 R79 or R77 or R85
Main principle Superheterodyne (common)
Wave bands Broadcast (MW) and Long Wave.
Details
Power type and voltage Storage and/or dry batteries / 4 & 120 Volt
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: Sfer 28 5051 [modèle 1930, 2 boutons] - Radiola marque
Material Wooden case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Notes

Ce modèle a été livré en deux exécutions d'ébénisterie.

Le prédécesseur de ce modèle est la Sfer 28 avec 3 boutons de la saison 1928/1929.

Price in first year of sale 990.00 FRF
Mentioned in -- Original prospect or advert (L'Ouest-Éclair (Rennes), 27.12.1929)
Literature/Schematics (1) -- Original prospect or advert (Dépliant RL 531)

Model page created by John Koster. See "Data change" for further contributors.



All listed radios etc. from Radiola (marque)
Here you find 818 models, 508 with images and 243 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
