Litz-Total Rimlock
Radio-MJ (M.-J.); Paris
- Country
- France
- Manufacturer / Brand
- Radio-MJ (M.-J.); Paris
- Year
- 1951
- Category
- Broadcast Receiver - or past WW2 Tuner
- Radiomuseum.org ID
- 322903
Click on the schematic thumbnail to request the schematic as a free document.
- Number of Tubes
- 3
- Main principle
- TRF with regeneration
- Wave bands
- Broadcast (MW) and Long Wave.
- Power type and voltage
- AC/DC-set
- Loudspeaker
- Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 17 cm = 6.7 inch
- Material
- Wooden case
- from Radiomuseum.org
- Model: Litz-Total Rimlock - Radio-MJ M.-J.; Paris
- Shape
- Tablemodel, with any shape - general.
- Notes
-
Bloc HF Tesla "Litz total", primaire et secondaire isolés à noyau magnétique et couplage variable.
Réaction type Reinartz.
- Price in first year of sale
- 6,020.00 FRF
- Mentioned in
- Le Haut-Parleur (No. 894, Mai 1951)
- Author
- Model page created by Jean Marchal. See "Data change" for further contributors.
