• Country
• Great Britain (UK)

• Manufacturer / Brand
• Radiomobile Ltd., Cricklewood Works, London

• Year
• 1964 ?

• Category
• Car Radio, perhaps also + sound player/recorder

• Radiomuseum.org ID
• 175419

• • alternative name: S.Smith and Sons

Click on the schematic thumbnail to request the schematic as a free document.

• Number of Transistors
• 7

• Semiconductors
• AF117 AF117 AF117 OC82D OC82D AD140 AD140

• Main principle
• Superhet with RF-stage; ZF/IF 456 kHz; 3 AF stage(s)

• Tuned circuits
• 7 AM circuit(s)

• Wave bands
• Broadcast only (MW).

• Power type and voltage
• Storage Battery for all (e.g. for car radios and amateur radios) / 12 Volt

• Loudspeaker
• - This model requires external speaker(s).

• Material
• Metal case

• from Radiomuseum.org
• Model: 922T - Radiomobile Ltd., Cricklewood

• Shape
• Chassis only or for «building in»

• Source of data
• -- Schematic

• Circuit diagram reference
• Radio and TV Servicing books (R&TVS) book

• Author
• Model page created by Keith Staines. See "Data change" for further contributors.
