GF3; Radione RADIO (ID = 295180) Radio
Radione RADIO: GF3 [Radio] ID = 295180 770x700
Select picture or schematic to display from thumbnails on the right and click for download.
For model GF3, Radione (RADIO Nikolaus Eltz); Wien

Country:  Austria
Manufacturer / Brand:  Radione (RADIO Nikolaus Eltz); Wien
Year: 1930/1931 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 3: B2042 B2024 B2043
Conflicting model year with tube data.
The model date contradicts tube dates. [ B2043 (1931)]
Main principle TRF with regeneration
Tuned circuits 2 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Direct Current supply (DC)
Loudspeaker - This model requires external speaker(s).
Power out
from Radiomuseum.org Model: GF3 - Radione RADIO Nikolaus Eltz;
Material Metal case
Shape Tablemodel, Box - most often with Lid (NOT slant panel).
Dimensions (WHD) 375 x 205 x 195 mm / 14.8 x 8.1 x 7.7 inch
Notes Fernempfänger
Net weight (2.2 lb = 1 kg) 6.5 kg / 14 lb 5.1 oz (14.317 lb)
Price in first year of sale 310.00 ATS
External source of data E. Erb 3-907007-36-0
Source of data Radiokatalog Band 2, Ernst Erb


All listed radios etc. from Radione (RADIO Nikolaus Eltz); Wien
Here you find 513 models, 356 with images and 316 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
