• Year
  • 1959
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 192374

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • 6
  • Semiconductors
  • Main principle
  • Superheterodyne (common); ZF/IF 455 kHz
  • Tuned circuits
  • 5 AM circuit(s)
  • Wave bands
  • Broadcast (MW) and Long Wave.
  • Power type and voltage
  • Dry Batteries / 3 x 4,5 Volt
  • Loudspeaker
  • Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 12 cm = 4.7 inch
  • Power out
  • 0.2 W (unknown quality)
  • Material
  • Plastics (no bakelite or catalin)
  • from Radiomuseum.org
  • Model: Solistor S595T - Radio Popular; București -
  • Shape
  • Portable set > 8 inch (also usable without mains)
  • Dimensions (WHD)
  • 251 x 172 x 93 mm / 9.9 x 6.8 x 3.7 inch
  • Notes
  • Licence production of the Clarville Solistor 59.
  • Net weight (2.2 lb = 1 kg)
  • 2.2 kg / 4 lb 13.5 oz (4.846 lb)
  • Literature/Schematics (1)
  • Scheme de Radioreceptoare; Ed. Tehnica, 1973
  • Author
  • Model page created by Francisc VISKY. See "Data change" for further contributors.

 Collections | Museums | Literature

Collections

The model Solistor is part of the collections of the following members.

 Forum

Forum contributions about this model: Radio Popular;: Solistor S595T

Threads: 1 | Posts: 6

 I tried to upload a new model Solistor manufactured by Radio Popular Bucharest under the type name S593T. But I can not afford it because the field “Manufacturer/Brand “it not filling up. The model is similar with the Solistor 59 manufactured by Clarville.

Bild verkleinert.

Francisc VISKY, 21.Feb.11
