Riga 6; Radiotehnika RT - (ID = 192900) Radio
Radiotehnika RT -: Riga 6 [Radio] ID = 192900 672x511
Select picture or schematic to display from thumbnails on the right and click for download.
For model Riga 6, Radiotehnika (RT) - after 1951 RRR Rigas Radio Rupnica; Riga:
Kaunas Lithuania

Country:  Latvia (Latvia, Riga)
Manufacturer / Brand:  Radiotehnika (RT) - after 1951 RRR Rigas Radio Rupnica; Riga
alternative name

A. Ss. Popow, Riga || Kandava Radio Works || Riga Popov Radiotechnika Works
Year: 1952–1955 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6А7 6Б8С 6Ж8 6П6С 6Е5С 5Ц4С
Main principle Superheterodyne (common); ZF/IF 464 kHz
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110/220 Volt
Loudspeaker
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: Riga 6 - Radiotehnika RT - after 1951
Material Various materials
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 440 x 325 x 230 mm / 17.3 x 12.8 x 9.1 inch
Notes Riga 6 - 2nd class radio receiver , Metallgehäuse mit Bakelit-Front
Net weight (2.2 lb = 1 kg) 12 kg / 26 lb 6.9 oz (26.432 lb)
Source of data -- Schematic
Mentioned in Past Soviet Union magazine RADIO Nr. 8, 1952

Model page created by Nikolaj Baranov. See "Data change" for further contributors.



All listed radios etc. from Radiotehnika (RT) - after 1951 RRR Rigas Radio Rupnica; Riga
Here you find 98 models, 96 with images and 61 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
