Riga 6 half closed magic eye

Riga 6; Radiotehnika RT - (ID = 484459) Radio Riga 6; Radiotehnika RT - (ID = 484463) Radio
Riga 6; Radiotehnika RT - (ID = 484468) Radio Riga 6; Radiotehnika RT - (ID = 484460) Radio
Riga 6; Radiotehnika RT - (ID = 484462) Radio Riga 6; Radiotehnika RT - (ID = 484464) Radio
Riga 6; Radiotehnika RT - (ID = 484465) Radio Riga 6; Radiotehnika RT - (ID = 484467) Radio
Riga 6; Radiotehnika RT - (ID = 883264) Radio Riga 6; Radiotehnika RT - (ID = 883265) Radio
Use red slider bar for more.
Riga 6; Radiotehnika RT - (ID = 484459) Radio
Radiotehnika RT -: Riga 6 [Radio] ID = 484459 659x493
Select picture or schematic to display from thumbnails on the right and click for download.
For model Riga 6 half closed magic eye, Radiotehnika (RT) - after 1951 RRR Rigas Radio Rupnica; Riga:
Kaunas Lithuania

Country:  Latvia (Latvia, Riga)
Manufacturer / Brand:  Radiotehnika (RT) - after 1951 RRR Rigas Radio Rupnica; Riga
alternative name

A. Ss. Popow, Riga || Kandava Radio Works || Riga Popov Radiotechnika Works
Year: 1952 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 6А7 6Б8С 6Ж8 6П6С 6Е5С 5Ц4С
Main principle Superheterodyne (common); ZF/IF 464 kHz
Wave bands Broadcast, Long Wave and 2 x Short Wave.
Details
Power type and voltage Alternating Current supply (AC) / 110; 220 Volt
Loudspeaker
Power out 1.5 W (unknown quality)
from Radiomuseum.org Model: Riga 6 [half closed magic eye] - Radiotehnika RT - after 1951
Material Various materials
Shape Tablemodel, with any shape - general.
Dimensions (WHD) 440 x 325 x 230 mm / 17.3 x 12.8 x 9.1 inch
Notes 2nd class radio receiver, Metallgehäuse mit Bakelit-Front.
Another radio case front panel design as in Mod ID-76691.
Net weight (2.2 lb = 1 kg) 12 kg / 26 lb 6.9 oz (26.432 lb)
Mentioned in Past Soviet Union magazine RADIO Nr. 8, 1952

Model page created by Zenonas Langaitis. See "Data change" for further contributors.



All listed radios etc. from Radiotehnika (RT) - after 1951 RRR Rigas Radio Rupnica; Riga
Here you find 98 models, 96 with images and 61 with schematics for wireless sets etc. In French: TSF for Télégraphie sans fil.
