Abschluss-Widerstand AW 742

Abschluss-Widerstand AW 742; Rafena Werke (ID = 2393367) Equipment

Abschluss-Widerstand AW 742; Rafena Werke (ID = 2393368) Equipment

Abschluss-Widerstand AW 742; Rafena Werke (ID = 2393369) Equipment
Abschluss-Widerstand AW 742; Rafena Werke (ID = 2391891) Equipment Abschluss-Widerstand AW 742; Rafena Werke (ID = 2391892) Equipment
Abschluss-Widerstand AW 742; Rafena Werke (ID = 2391893) Equipment Abschluss-Widerstand AW 742; Rafena Werke (ID = 2391894) Equipment
Use red slider bar for more.
Abschluss-Widerstand AW 742; Rafena Werke (ID = 2391891) Equipment
Rafena Werke: Abschluss-Widerstand AW 742 [Equipment] ID = 2391891 1400x578
Select picture or schematic to display from thumbnails on the right and click for download.
For model Abschluss-Widerstand AW 742, Rafena Werke Radeberg, VEB; Radeberg (Ostd.):
aus der technischen Dokumentation des Herstellers

Country:  Germany
Manufacturer / Brand:  Rafena Werke Radeberg, VEB; Radeberg (Ostd.)
Brand

VEB Rafena; Radeberg (Ostd.)
Year: 1956 Category: Service- or Lab Equipment
Wave bands Wave Bands given in the notes.
Details
Power type and voltage No Power needed
Loudspeaker - - No sound reproduction output.
Power out
from Radiomuseum.org Model: Abschluss-Widerstand AW 742 - Rafena Werke Radeberg, VEB;
Material Metal case
Dimensions (WHD) 283 x 50 x 50 mm / 11.1 x 2 x 2 inch
Notes

Wellenbereich: 20,5...25 cm,

Wellenwiderstand: Z = 70 Ω,

Eingangswiderstand: R = 70 Ω,

Anpassung m = Umin/Umax >= 0,85

Belastung max. 10 W.



Net weight (2.2 lb = 1 kg) 0.450 kg / 0 lb 15.9 oz (0.991 lb)
Mentioned in - - Manufacturers Literature

Model page created by Wolfgang Lill. See "Data change" for further contributors.
