• Year
  • 1972
  • Category
  • Broadcast Receiver - or past WW2 Tuner
  • Radiomuseum.org ID
  • 142104
    • Brand: Arena

Click on the schematic thumbnail to request the schematic as a free document.

 Technical Specifications

  • Number of Transistors
  • Semiconductors present.
  • Semiconductors
  • Main principle
  • Superheterodyne (common)
  • Wave bands
  • Broadcast (BC) and FM or UHF.
  • Power type and voltage
  • Alternating Current supply (AC) / 220 Volt
  • Loudspeaker
  • - This model requires external speaker(s).
  • Power out
  • 40 W (unknown quality)
  • Material
  • Wooden case
  • from Radiomuseum.org
  • Model: R1020 - Rank-Arena, Horsens
  • Shape
  • Book-shelf unit.
  • Dimensions (WHD)
  • 450 x 108 x 300 mm / 17.7 x 4.3 x 11.8 inch
  • Notes
  • HiFi-Stereo-AM/FM-Receiver mit 2× 20 Watt Sinus an 4 Ohm.
    Silent-Tuning bei FM. Endstufensicherung gegen Überlast.
    Gehäuse in Nussbaum oder Weiss.
  • Net weight (2.2 lb = 1 kg)
  • 7.550 kg / 16 lb 10.1 oz (16.63 lb)
  • Source of data
  • -- Original prospect or advert
  • Author
  • Model page created by Franz Scharner. See "Data change" for further contributors.
