• Country
• Finland

• Manufacturer / Brand
• Radioteollisuus, Helsinki

• Year
• 1948 ?

• Category
• Broadcast Receiver - or past WW2 Tuner

• Radiomuseum.org ID
• 282000

• Number of Tubes
• 9

• Valves / Tubes
• ECH21 EF22 EF22 EB11 REN904 REN904 6V6G 6V6G RGN2005

• Main principle
• Superheterodyne (common)

• Wave bands
• Broadcast, Long Wave and Short Wave.

• Details
• Record Player (perh.Changer)

• Power type and voltage
• Alternating Current supply (AC) / 127/220 Volt

• Loudspeaker
• 2 Loudspeakers

• Power out
• 8 W (unknown quality)

• Material
• Wooden case

• from Radiomuseum.org
• Model: 2825V - Radioteollisuus, Helsinki

• Shape
• Console, Lowboy (legs < 50 %).

• Dimensions (WHD)
• 800 x 960 x 480 mm / 31.5 x 37.8 x 18.9 inch

• Notes

• Record player can be also without changer.

  Two Loudspeakers 10" and 3"

• Mentioned in
• - - Manufacturers Literature

• Author
• Model page created by a member from FIN. See "Data change" for further contributors.
