CR-43A Ch= 4D16-A

CR-43A Ch= 4D16-A; Raytheon Mfg. Co.; (ID = 215942) Radio

CR-43A Ch= 4D16-A; Raytheon Mfg. Co.; (ID = 215943) Radio

CR-43A Ch= 4D16-A; Raytheon Mfg. Co.; (ID = 982443) Radio

CR-43A Ch= 4D16-A; Raytheon Mfg. Co.; (ID = 982444) Radio

CR-43A Ch= 4D16-A; Raytheon Mfg. Co.; (ID = 982445) Radio

CR-43A Ch= 4D16-A; Raytheon Mfg. Co.; (ID = 982446) Radio
Use red slider bar for more.
CR-43A Ch= 4D16-A; Raytheon Mfg. Co.; (ID = 215942) Radio
Select picture or schematic to display from thumbnails on the right and click for download.

Country:  United States of America (USA)
Manufacturer / Brand:  Raytheon Mfg. Co.; Cambridge, MA
Year: 1953 perfect model Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 4: 12BE6 12BA6 12AV6 or 12AT6 50C5
Main principle Superheterodyne (common); ZF/IF 455 kHz; 2 AF stage(s)
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast only (MW).
Details
Power type and voltage Alternating Current supply (AC) / 115 Volt
Loudspeaker Permanent Magnet Dynamic (PDyn) Loudspeaker (moving coil) / Ø 4 inch = 10.2 cm
Power out
from Radiomuseum.org Model: CR-43A Ch= 4D16-A - Raytheon Mfg. Co.; Cambridge,
Material Modern plastics (no Bakelite or Catalin)
Shape Tablemodel with Clock ((Alarm-) Clock Radio).
Notes

According to SAMS Photofact 212-5 from August 1953 the chassis 4D16-A was first used for the models CR41, CR41-A (both Mahogany), CR42, CR42-A (both Ivory), CR43, CR43-A (both in Red) with the same cabinet - and for Western Auto models Truetone D2216A and D2217A. Built in loop antenna, single Selenium Rectifier. The manual of 1952 "most-often-needed radio diagrams" shows under Montgomery Ward also the Airline Clock Radios models 15BR-1548A, 15BR-1549A, 25BR-1548B and 25BR-1549B for this chassis, which are documented in Photofact 191-3 from January 1953.

Raytheon used its chassis 4D16-A tater also for three Alarm-Clock Radio models with the same cabinet in different colors: Model C-50B is in Walnut, Model C-51W is in White and Model C-52R is in Red. See also Beitman volume R-16 from 1956.

Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 23 (last), covering up to 1954

Model page created by Peter Rutishauser. See "Data change" for further contributors.
