121 ; RCA RCA Victor Co. (ID = 837652) Radio
RCA RCA Victor Co.: 121 [Radio] ID = 837652 733x933
Select picture or schematic to display from thumbnails on the right and click for download.
For model 121, RCA (RCA Victor Co. Inc.); New York (NY):
ebay 190455170935 937morse

Country:  United States of America (USA)
Manufacturer / Brand:  RCA (RCA Victor Co. Inc.); New York (NY)
alternative name

RCA Manufacturing || Victor Talking Machine
Year: 1933 Category: Broadcast Receiver - or past WW2 Tuner
Valves / Tubes 6: 58 2A7 58 2B7 2A5 80
Main principle Superhet with RF-stage; ZF/IF 370 kHz
Tuned circuits 6 AM circuit(s)
Wave bands Broadcast and Short Wave (SW).
Details
Power type and voltage Alternating Current supply (AC) / 100-125 Volt
Loudspeaker Electro Magnetic Dynamic LS (moving-coil with field excitation coil)
Power out 1.75 W (unknown quality)
from Radiomuseum.org Model: 121 - RCA RCA Victor Co. Inc.; New
Material Wooden case
Shape Table-Cathedral-Type (upright, round top or gothic arch, not rounded edges only).
Price in first year of sale 52.50 USD
External source of data Ernst Erb
Source of data The Radio Collector's Directory and Price Guide 1921 - 1965
Circuit diagram reference Rider's Perpetual, Volume 4 = ca. 1934 and before
Mentioned in Collector's Guide to Antique Radios 4. Edition
Literature/Schematics (1) RCA Victor Service Notes "Red Book" Series
Literature/Schematics (2) Table Top Radios Vol. 1 Stein 98 (page 137.)
Literature/Schematics (3) Cathedral & Tombstone Radios (page 218.)
